Suitable for: Langstroth 1/1, Langstroth honey super, Austrian wide comb, Kuntzsch wide and Gerstung. Maximum frame size: 26.5 x 48 cm (top-bar length).
Cassette size: 27.5 x 40 x 4.5 cm
Drive: 250 W / 230 V motor with fully automatic control
Inner diameter of the tank: 82 cm
6-frame self-reversing honey extractor by Logar, driven by a 250 W / 230 V motor with fully automatic control and an integrated safety device that automatically shuts off the motor when the lid is opened. The extractor is fitted with two stainless squeeze valves 6/4''; one is welded in at the lowest point so that all honey can drain out. All parts that come into contact with honey are made from food-grade materials. The lid is made of transparent acrylic glass.
The frame cassettes are made from vertical grid rods of appropriate density so that frames are not damaged during extraction. They are linked together by a special mechanism. The cassettes prevent honey from pooling during extraction, so frames are dry after spinning. For an additional charge, cassettes for frames up to 28 cm high are available.
The extractor is detachable and can therefore be transported through an 80 cm door opening without difficulty. The fully automatic controller allows the entire extraction process to be carried out automatically; operation is via a membrane keypad and a dual-line digital LCD. Up to 8 programs, each with up to 8 times, directions and speeds, can be set and saved. Basic programs are preset and freely adjustable.
Compact design, quiet operation and reliable performance. Warranty: 2 years. Art. No. 4300.
Optional equipment:
• Bottom heater for honey extractor Ø 82 cm incl. installation – our recommendation for faster honey flow, quicker sieving and easier cleaning (Art. No. 7128)
• Voltage converter 12V DC → 230V AC, 600 W for use with a 12V battery if 230V is not available (Art. No. 4627)
• Rubber pads for the feet to reduce slipping (Art. No. 7769)
- Type: LTA 6SS-S
- Material: Stainless steel W.Nr. 1.4301 / AISI 304
- Drive: Programmed fully automatic with 250 W / 230 V motor, fully automatic control, integrated safety device (motor shuts off when lid is opened)
- Number of frames (deep / shallow): 6 / 6
- Suitable for: Langstroth 1/1, Langstroth honey super, Austrian wide comb, Kuntzsch wide, Gerstung
- Cassette size: 27.5 x 40 x 4.5 cm
- Maximum frame: 26.5 x 48 cm (top-bar length)
- Tank diameter (inside / outside): 82 / 86 cm
- Total height (with feet / with drive): 112 / 132 cm
- Tank height (without / with drive): 75 / 97 cm
- Height from floor to honey valve: 37 cm
- Honey valves: 2 x Ø 42 mm, one welded at the lowest point; base welded seamless and inclined towards the squeeze valve
- Lid: transparent acrylic glass
- Frame cassettes: vertical grid rods, dry result after extraction; optional version up to 28 cm height available at extra cost
- Special features: Detachable (transport through 80 cm door opening), quiet operation, reliable performance
- Origin: Made in the EU (Slovenia)
- Warranty: 2 years
